Need Complete Physical Portals, Tags & On-Site Setup?
Beyond software, we engineer complete turnkey packages: RFID turnstiles, biometric POS kiosks, UHF Gen2 cards, and ERP sync (SAP S/4HANA & Tally).
Technical Architecture & System Compatibility
Chainway C72 / C71 Handheld Scanners, Zebra RFD40 Sleds, Overhead Portal Interrogators.
Docker Containerized, Ubuntu Linux, Windows Server, PostgreSQL, MS SQL, MongoDB. Air-gapped on-premise or cloud.
SAP S/4HANA (BAPI/RFC), TallyPrime (XML Gateway), Oracle NetSuite, MS Dynamics 365, Swagger REST APIs.
What's Included in Your Solution License
Immediate DeliveryIT & Fixed Asset Tracking
Enterprise RFID Fixed Asset Tracking Software
Data Center Server Audits, Laptop Tracking, Depreciation & AMC Lifecycle
Choose Your Deployment Tier
Software & Cloud Infrastructure Only: Physical RFID hardware (readers, antennas, tags) is not included in the base subscription. Compatible with client BYOD (Zebra, Chainway, Impinj) or configure as a complete turnkey package below ↓.
- ✓Free Community Plan: Test live immediately with 50 active items / stock units and 1 reader.
- ✓Zero DevOps Overhead: Fully hosted by RFID Softwares on high-availability Google Cloud clusters.
- ✓Automatic Upgrades: Continuous bug fixes, feature releases, and daily encrypted cloud backups.
- •Strict quota tiers (2.5k, 15k, 50k tags). For unlimited scans, choose Isolated Self-Hosted below.
Enterprise Assurances
Need a Live System Demo or Pilot Setup?
Test the solution in your staging environment before organization-wide rollout. We provide complete sandbox instances, hardware loaners, and architecture walk-throughs.
Description
Specifications
- Asset Types
- IT Hardware (Laptops, Servers, Switches), Office Furniture, Tooling, Heavy Machinery
- Audit Speed
- Audit up to 2,500 assets per hour per handheld operator with real-time discrepancy lists
- Depreciation Standards
- Companies Act 2013 & Income Tax Act Schedule II (SLM / WDV automated schedules)
- Tag Types Supported
- Ceramic on-metal tags, flexible printable anti-metal labels, tamper-evident tags
- Evaluation Quota
- Universal 50 active items / stock units quota on app.rfidsoftwares.com
Industrial GPIO Pinout & Modbus TCP Register Map
Hardware wiring specifications for connecting Enterprise RFID Fixed Asset Tracking Software | Cloud Tiers & Turnkey Kit Pricing directly to optical photocell sensors, light stacks, and Siemens / Allen-Bradley PLCs.
Instead of keeping the RFID scanner running 24/7 (which overheats equipment and reads distant tags accidentally), a physical light beam sensor (photocell) tells the reader to scan only when a box arrives on the conveyor belt. If the box has a missing or wrong tag, the reader instantly trips a red light and signals a robotic arm or pneumatic pusher to divert the box.
- 1 Optical Beam Cut: Carton cuts photocell beam → GPI-1 transitions from 0V to +24V HIGH.
- 2 1,500ms Active Scan: Reader powers RF antenna array (30 dBm) and captures all tag EPCs inside the carton.
- 3 ERP Validation: If carton count matches ERP manifest, GPO-1 pulses for 200ms (Green Light / Belt Continues).
- 4 Defect Ejection: If tag count is incomplete, GPO-2 triggers pneumatic diverter to route carton to audit lane.
PLC Modbus TCP Register Memory Mapping (Siemens S7-1200 / Rockwell CompactLogix)
| Register Address | Data Type | Access | Description & PLC Interpretation |
|---|---|---|---|
| 40001 | UINT16 | Read-Only | Reader Status: 0=Idle, 1=Scanning Active, 2=Fault/Overheat |
| 40002 | UINT16 | Read-Only | Total Unique Tags Captured in Current Trigger Cycle |
| 40003–40008 | 6 x UINT16 | Read-Only | 96-bit Hex EPC Data of Primary Verified Tag |
| 40009 | INT16 | Read-Only | Peak Signal RSSI (e.g. -48 dBm) for RF coverage tuning |
| 40101 | UINT16 | Read/Write | PLC Software Trigger Override: Write 1 to start inventory cycle |
UHF RFID Read Range & Link Budget Estimator
Safe operational limit with multipath mitigation & antenna detuning buffer.
Maximum line-of-sight range in ideal non-metallic open air.
Watch Enterprise RFID Fixed Asset Tracking Software | Cloud Tiers & Turnkey Kit Pricing in Action
Real field testing and operational validation demonstration conducted at our lab & partner facilities. Demonstrates read distance, physical durability, and live interrogation.
Configure Your Complete Enterprise RFID Fixed Asset Tracking & IT Hardware Management System Package
Analyze metallic reflections and locate tagged server racks and IT hardware across multi-floor rooms.
Step 1: Choose Software Commercial Licensing
Zero Vendor Lock-InStep 2: Select Handheld RFID Mobile Scanner
Chainway C72 UHF Handheld Reader
✓Massive 8,000 mAh swappable battery for 12+ hr continuous shifts
✓750+ tags/second ultra-fast scan rate with Impinj E710 / R2000 module
•Slightly heavier in hand due to 8,000 mAh battery pack
Packseals G2 UHF Handheld Scanner
✓Most affordable entry price (Save ₹20,000 per unit)
✓Modern Android 13 operating system with snappy capacitive touch
•Newer brand with shorter market history in India
Chainway C71 UHF Handheld Reader
✓8+ years proven operational track record across Indian industries
✓Extremely stable JNI drivers and native C++ SDK wrappers
•Older chassis ergonomics compared to newer C72
Zebra RFD40 Premium UHF Sled Scanner
✓Industry-leading 1,300+ tags/second interrogation speed
✓Global #1 enterprise AIDC brand with Zebra OneCare SLA
•Premium capital expense (~2x to 3x higher price point)
Step 4: Specialized RFID Tags & Smart Badges
Dielectric & Sub-Zero TunedDirect mount on metal server chassis, desktop CPUs, network switches, and aluminum laptops
Office chairs, wooden desks, plastic monitor frames, conference room projectors
Step 5: Optional Services & Enterprise Connectors
Certified RF EngineersEstimated Project Package
Ask our AI RF Engineer to inspect your active configuration and suggest layout adjustments.
Interactive RFID Engineering Tools & Calculators
Use our free interactive calculators and simulators to model RF physics, calculate link budgets, estimate ROI, and configure EPC tags.
RFID Link Budget Calculator
Calculate reader EIRP (+36 dBm WPC), antenna gain (dBi), path loss, and receiver sensitivity threshold (-86 dBm).
Antenna Coverage & Beamwidth Calculator
Model 3dB azimuth/elevation beam footprints and coverage radii for warehouse dock doors and conveyor gates.
RFID Portal Velocity Calculator
Estimate tag dwell times, maximum conveyor transit speeds (m/s), and read rates under dense tag environments.
Questions
Can this software detect if a tagged laptop is taken out of the building without approval?
