Noida RF Test Lab Certified 100% Pre-Dispatch Burn-In

Bench Tested & Frequency Calibrated

Every hardware reader and handheld is tested for RF sensitivity, power output, and GPIO triggering at our Noida facility. Fully calibrated for India WPC 865.0–867.0 MHz with test certificate.

Enterprise Hardware Standards & Deliverables

WPC India Approved

865–867 MHz WPC India ETA

ISO 18000-6C EPC Class 1 Gen 2

PoE+ & GPIO Industrial I/O

Same-Week Noida Lab Dispatch

Handheld SDK Wrappers

Chainway C72 / C66 Android Handheld SDK Middleware Bridge

Name: RFID Softwares
Address: Gate No 1, Plot No 217, Gali No. 7, near AMRAPALI SAPPHIRE, Sadarpur Colony, Village Chhalera & Sadarpur, Sadarpur, Sector-45, Noida, Uttar Pradesh 201301, Noida, Uttar Pradesh, 201301, IN
Telephone: +91 9791492742

Native Android Broadcast Receiver, Offline SQLite Storage & Real-Time REST Sync

✨Simple Explanation with AI Range: Up to 15 meters on standard UHF inlays; up to 8 meters on ceramic on-metal tags

Commercial Licensing Model

100% Full Source Code Ownership & Perpetual License

Zero SaaS Subscriptions

₹1,25,000One-Time Buyout (Perpetual License)

Royalty-Free

This middleware connector operates on-premise inside your internal corporate LAN, edge industrial PCs, and factory networks behind strict corporate firewalls. It is not sold as a multi-tenant cloud subscription.

Included Source Code & Deliverables:

✓Complete uncompiled source code (C# .NET 8 / C++ / Node.js Git repository)

✓Native ERP connectors (SAP RFC BAPI / Tally XML Port 9000 / LLRP sockets)

✓SQLite WAL local offline buffer engine (0% lost inventory during network drops)

✓100% royalty-free perpetual license with unmetered readers & dock doors

✓90 days direct developer integration walkthrough & engineering support

Request Source Code License & NDA 🧪 Test in Virtual Simulator

Request Software Demo & Architecture Call Instant Quote on WhatsApp

Developer & ERP Integration Kit Android & Tally

Direct .NET/Android SDK wrapper & TallyPrime stock sync middleware.

Chainway C72 / C71 SDK & Middleware

Enterprise Assurances

1-Year OEM Warranty

Android SDK & API Docs

Pan-India Dispatch

Pre-Tested Demo Ready

Need Custom Handheld App or ERP Sync?

Don't let handhelds arrive blank. We build custom Android APKs for stocktaking, asset audits, and real-time offline sync with Tally Prime, SAP S/4HANA, and custom WMS.

Book Feasibility Call Handheld Middlewares

Description

Specifications

Supported Terminals: Chainway C72, C66, C71, C70, SEUIC AutoID, UROVO DT50, Newland
Android Compatibility: Android 8.1 Oreo through Android 14 with 64-bit ARM architecture
Scan Rate: Up to 750 tags per second with 4 dBi circular polarized integrated antenna
Read Range: Up to 15 meters on standard UHF inlays; up to 8 meters on ceramic on-metal tags
Data Export: Direct REST API POST, MQTT stream, CSV export, and native Bluetooth SPP/HID

Developer Integration Kit • OpenRFID Ready

Hardware SDK & Edge API Quickstart

Connect, configure RF power (10–33 dBm), and stream tag inventory to your ERP / backend in under 5 minutes.

Protocol

LLRP / RS-232 / REST

Read Rate

Up to 750 tags/sec

💡

Why this matters to your business: You are not locked into proprietary software. Our open integration drivers allow your internal IT team or ERP vendor (SAP, Tally, Zoho, Oracle) to directly ingest live RFID scans without expensive recurring middleware licensing fees.

RfidReaderIntegration.cs

API Ready

using OpenRFID.Core.Drivers;
using OpenRFID.Core.Models;

// 1. Initialize TCP/LLRP Connection
using var cts = new CancellationTokenSource(TimeSpan.FromSeconds(30));
var reader = new OpenRfidClient(ip: "192.168.1.120", port: 5084);

await reader.ConnectAsync(cts.Token);
await reader.SetPowerAsync(antennaId: 1, txPowerDbm: 30.0); // India WPC 865-867 MHz

// 2. Stream Real-time RFID Inventory Events with Lock-Free Channel
await foreach (var tag in reader.StreamTagsAsync(cts.Token))
{
    Console.WriteLine("[LIVE READ] EPC: " + tag.EpcHex + " | RSSI: " + tag.RssiDbm + " dBm");

    // Dispatches directly to SAP / Tally / SQL Database queue
    await erpBridge.PushBatchAsync(tag);
}

import asyncio
import json

# Async Socket Streaming Client
async def stream_rfid_inventory(host="192.168.1.120", port=5084):
    reader, writer = await asyncio.open_connection(host, port)
    print("Connected to RFID Reader at " + host + ":" + str(port))

    try:
        while True:
            line = await reader.readline()
            if not line: break
            tag = json.loads(line.decode('utf-8'))
            print("[TAG DETECTED] EPC=" + str(tag['epc']) + ", RSSI=" + str(tag['rssi']))
    finally:
        writer.close()
        await writer.wait_closed()

asyncio.run(stream_rfid_inventory())

import com.rscja.deviceapi.RFIDWithUHFUART
import com.rscja.deviceapi.entity.UHFTAGInfo

// 1. Initialize Handheld UHF Hardware Module
val uhf = RFIDWithUHFUART.getInstance()
uhf.init()
uhf.power = 30 // 30 dBm Max Output for 865-867 MHz WPC

// 2. Start Continuous High-Speed Trigger Scanning
uhf.startInventoryTag { tag: UHFTAGInfo ->
    val epc = tag.epc
    val rssi = tag.rssi

    SoundUtils.playBeepSound()
    Log.d("UHF", "Scanned EPC: " + epc + " Signal: " + rssi + " dBm")
}

# Push real-time batch scan payload to OpenRFID Cloud Ingestion API
curl -X POST https://api.rfidsoftwares.com/v1/ingest/batch \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_API_TOKEN" \
  -d '{
    "readerId": "chainway-c72-android-sdk-middleware",
    "warehouseId": "WH-MUMBAI-01",
    "timestamp": "2026-09-28T14:30:00Z",
    "tags": [
      { "epc": "E28011606000020478059012", "rssi": -48.5, "antenna": 1, "count": 14 },
      { "epc": "E28011606000020478059013", "rssi": -52.1, "antenna": 2, "count": 8 }
    ]
  }'

📦 Verified SDK Download Packs & Technical Guides

Production Tested

Integration Blueprint 📖

Complete step-by-step Android Studio, JNI C++ bindings & TallyPrime XML HTTP tutorial.

Read Integration Guide →

Turnkey Middleware APK ⚡

Pre-built zero-code Android bridge app with background tag de-duplication and direct SAP/Tally sync.

View Middleware Details →

Android SDK & JNI AAR 📥

Includes DeviceAPI_ver2024.aar, sample Android Studio Kotlin workspace, and RS-232 UART driver.

Request SDK Download Bundle →

⌨️ Virtual Keyboard Wedge & Zero-Code Intent Broadcast App: 2D Barcode / KeyboardEmulator

Need to scan RFID tags directly into Google Sheets, browser forms, or ERP mobile apps without coding? Set the built-in KeyboardEmulator utility to:

Output Mode: Keyboard / Intent

Broadcast Action: com.rscja.android.KEY_DOWN

Data String Extra: data

Auto Suffix: Enter (\n) / Tab (\t)

🔋

8000mAh High-Capacity Swappable Battery: Provides 12+ continuous hours of active RF trigger scanning. Dual-slot desktop cradle available.

Drop Spec: 1.5m Concrete | IP65 Sealed

Supports SAP S/4HANA TallyPrime Ready Sub-10ms Latency WPC Certified (865–867 MHz)

Download C72 Android SDK & Guide RFD40 vs C72 Benchmark Explore Middleware Catalog

Friis Transmission Physics & WPC 865–867 MHz

UHF RFID Read Range & Link Budget Estimator

1. Reader Conducted RF Power (dBm)

10 dBm (Handheld Low)27 dBm (Handheld High)30 dBm (Standard Fixed)33 dBm (Max Port)

2. Antenna Gain (dBi)

Polarization Type

3. Coaxial Cable Type

Cable Length5m (0.64 dB Loss)

4. Tag IC Transponder Chip Sensitivity

5. Operating Environment

Calculated Range & Link Metrics

Recommended Working Distance (Warehouse Reliability 99.5%):

8.5m(28.0 Feet)

Safe operational limit with multipath mitigation & antenna detuning buffer.

Theoretical Free-Space Maximum:

12.2m(40.0 Feet)

Maximum line-of-sight range in ideal non-metallic open air.

Total Radiated EIRP:38.4 dBm (6.85 W)

WPC Legal Ceiling (India):36.0 dBm (4.0 W EIRP)

Coaxial Cable Attenuation:-0.64 dB

Forward Link Margin:+60.9 dB

ℹ️All fixed readers deployed by RFID Softwares hold certified WPC Equipment Type Approval (ETA) for 865–867 MHz operation.

Live Demonstration

Watch Chainway C72 / C66 Android Handheld SDK Middleware Bridge | Java & C++ JNI in Action

Browse All Video Blueprints →

Real field testing and operational validation demonstration conducted at our lab & partner facilities. Demonstrates read distance, physical durability, and live interrogation.

Packaging & Accessories

What's in the Box & Hardware Blueprint

Every unit is factory-inspected, serialized, and paired with essential deployment accessories.

Handheld Industrial Mobile Terminal

Chainway C72 / Sled Reader Unit

1 Unit

Android OS with Impinj E710 / R2000 UHF module

Heavy-Duty Ergonomic Pistol Grip

1 Pc

Quick-fire trigger for continuous 750+ tag/s scanning

8000 mAh Rechargeable Li-ion Battery

1 Unit

Full 12-hour continuous operational shift runtime

Type-C Fast Charger & Data Cable

1 Set

Quick charging adapter with reinforced USB-C cord

Pre-Loaded OpenRFID Demo APK

Pre-Installed

Native JNI driver for instant inventory scanning

SDK Documentation & Serial Pinout

Digital / PDF

Kotlin, Java, and C# .NET MAUI wrapper guides

💡

Need a 14-Day Physical On-Site Pilot Evaluation?

We offer paid 14-day on-site pilot trials with demo setup in Delhi-NCR (minimum ~₹50,000+ demo POC fee + refundable hardware deposit). Remote-assisted starter packs available across India.

Book Paid Pilot Trial

Engineering & Planning Hub

Interactive RFID Engineering Tools & Calculators

Use our free interactive calculators and simulators to model RF physics, calculate link budgets, estimate ROI, and configure EPC tags.

View All 23 Developer Tools →

Range Sandbox Launch Tool →

RFID Read Range Calculator

Simulate maximum open-air vs indoor racking read distances (6m to 25m) based on tag sensitivity and reader power.

Open Interactive Calculator →

Productivity Launch Tool →

Cycle Count & Inventory Calculator

Quantify daily stocktaking labor hours saved by replacing 1D/2D manual scanning with 1,300+ tags/sec UHF sweeps.

Open Interactive Calculator →

Hardware Shootout Launch Tool →

RFID Reader Comparison Matrix

Side-by-side spec shootout comparing fixed multi-port readers, Android mobile guns, and modular RFID sleds.

Open Interactive Calculator →

Questions

Can we integrate this SDK into our existing React Native or Flutter mobile app?

Yes! We provide complete native bridging code and sample projects for React Native, Flutter, and native Android (Kotlin/Java).

Unit Price

₹1,25,000

WhatsApp Request Demo & Specs

RFID SOFTWARES

Enterprise RFID Hardware & Cloud Middleware Solutions

www.rfidsoftwares.com • info@rfidsoftwares.com • +91 9791492742

OFFICIAL TECHNICAL DATASHEET

Model / SKU: PRD_INT_CHAINWAY_C72

HSN Code: 85238020

Issued: 14 Oct 2026

RFID Integration

Chainway C72 / C66 Android Handheld SDK Middleware Bridge | Java & C++ JNI

Native Android Broadcast Receiver, Offline SQLite Storage & Real-Time REST Sync

Commercial & Procurement Summary

Catalog Price:	₹1,25,000 (+ 18% GST: ₹1,47,500)
Category / SubCategory:	Handheld SDK Wrappers
Procurement & Lead Time:	Ready Stock • Dispatched within 2–4 Business Days Across India
Warranty & Testing:	1-Year Comprehensive Warranty • 100% Pre-Shipment Tested & Calibrated

Executive Product Overview

Native Android SDK middleware bridge for Chainway C72 and C66 UHF mobile computers. Pre-built AAR library with Geiger-counter locating, SQLite cache, and ERP sync.

Technical Specifications & Operational Parameters

Engineering Parameter	Technical Specification / Capability
Supported Terminals	Chainway C72, C66, C71, C70, SEUIC AutoID, UROVO DT50, Newland
Android Compatibility	Android 8.1 Oreo through Android 14 with 64-bit ARM architecture
Scan Rate	Up to 750 tags per second with 4 dBi circular polarized integrated antenna
Read Range	Up to 15 meters on standard UHF inlays; up to 8 meters on ceramic on-metal tags
Data Export	Direct REST API POST, MQTT stream, CSV export, and native Bluetooth SPP/HID
