UHF RFID Portal Gates
HF RFID Security Gate System for Libraries and Retail
13.56 MHz ISO 15693 Corridor Gate, Purpose-Built for Libraries
₹2,80,000
★ 4.8
Prices are subject to change. Please contact us for a final quotation.
Description
The HF RFID Security Gate System for Libraries and Retail (Model: PRD_HW_HF_GATE) is an elegant, high-sensitivity 3D walk-through security portal engineered for public libraries, university research collections, legal archives, and luxury retail boutiques. Operating at 13.56 MHz High Frequency, this dual-pedestal system adheres to the international ISO/IEC 15693 and ISO/IEC 18000-3 Mode 1 standards, providing seamless anti-theft Electronic Article Surveillance (EAS) and patron circulation tracking across wide walk-through aisles.
1. 3D Omnidirectional Antenna Arrays & Wide Aisle Coverage
Featuring high-transparency architectural acrylic pedestals with internal multi-loop 3D antenna coils, the gate generates a uniform three-dimensional magnetic interrogation field. It detects tagged books, files, and media items at any orientation (flat, horizontal, vertical, or spine-angled) across an aisle detection width of up to 1.2 to 1.5 meters with 99%+ detection accuracy.
2. Koha ILS / 3M SIP2 Integration & Infrared Patron Counting
The master controller communicates in real-time with Koha ILS, Alma, and Sierra library management systems via Ethernet TCP/IP using the 3M SIP2 and NCIP protocols. It features built-in bi-directional infrared patron counting sensors that track visitor footfall traffic, loud multi-tone acoustic alarm sirens, flashing multi-color LED visual alert strobes, and dry contact relay outputs for automated turnstiles.
Specifications
- Model Number
- PRD-HF-GATE-ISO15693
- Operating Frequency
- 13.56 MHz High Frequency (HF)
- Protocol Standards
- ISO/IEC 15693 / ISO/IEC 18000-3 Mode 1 (ISO 28560 Ready)
- Supported Tag Chips
- NXP ICODE SLIX, ICODE SLIX2, TI Tag-it, Fujitsu HF Tags
- Pedestal Dimensions
- 1650 mm (H) × 500 mm (W) × 35 mm (D) (Per Pedestal)
- Pedestal Material
- High-Transparency Architectural Acrylic with Stainless Steel Base
- Detection Aisle Width
- 0.9 meters to 1.5 meters between Pedestals (Standard 1.2m)
- Antenna Orientation
- 3D 3-Axis Omnidirectional Interrogation Field
- Patron Counting
- Bi-Directional Infrared (IR) Beam Sensor with In/Out Visitor Analytics
- Controller Interfaces
- RJ45 10/100 Ethernet (TCP/IP), RS-232, USB, Relay Alarm Output
- Library ILS Protocols
- 3M SIP2 (Standard Interchange Protocol), NCIP, Koha REST API
- Power Supply
- 100V – 240V AC, 50/60 Hz (Power Consumption < 50W per Pair)
- Operating Temperature
- -10°C to +50°C (14°F to +122°F)
Verified Reviews
4.8 out of 5
Based on 4 verified client reviews.
Genuine Enterprise Feedback
Verified Project Deployments
Gohar, Founder at Fresh Book Technology
Verified Project
"The acrylic panels are highly aesthetic. Works perfectly with our Koha library automation system."
Tribhuvan Maheshwari, omkar astro founder (omkarastro.co.in)
Verified Project
"Very easy to install and calibrate. The walk-through rate is high and there are no false alarms."
Dr. Sarah Johnson, University Library Director
Verified Project
"Infrared passage sensors count visitor traffic while monitoring for un-checked library books."
Questions
How does the HF security gate interact with the Koha Library Management System?
When a patron borrows a book at the circulation desk or self-checkout kiosk, Koha communicates via the 3M SIP2 protocol to disarm the tag's EAS (Electronic Article Surveillance) security bit. If an unborrowed book passes through the exit gate, the gate detects the active EAS bit and triggers alarm sirens.
What is the maximum aisle width between the two acrylic gate pedestals?
The system provides a wide walk-through aisle of up to 1.5 meters (standard installation is 1.2 meters), ensuring comfortable, wheelchair-accessible, and high-volume patron flow.
Does the gate track how many visitors enter and exit the library daily?
Yes. Integrated bi-directional infrared (IR) beam sensors automatically count incoming and outgoing patrons, providing daily footfall reports and statistical analytics directly to library administrators.
What is the HSN Code and GST taxation for library RFID security gates in India?
Library security gates are classified under HSN Code 84719000 / 85437099 with an 18% GST rate. RFID Softwares provides complete hardware supply, installation, Koha SIP2 integration, and GST tax invoicing across India.
Can multiple pedestals be linked together for wide entrance lobbies?
Yes. Up to 4 pedestals can be synchronized with a single master controller to create a 3-aisle entry portal covering entrances up to 4.5 meters wide.
