RFID Tunnel & Conveyor Automation: High-Speed Verification Demo Demo

Industrial High-Speed Conveyor Portal with 4-Antenna Cross-Fire & GPIO Triggering

Live walkthrough & hardware operation testing. For itemized pricing, technical datasheets, and bulk procurement, view the official RFID Tunnel & Conveyor Automation: High-Speed Verification Demo product catalog page.

About this Video Demonstration

Laboratory demonstration of high-speed industrial RFID tunnel and conveyor automation scanning cartons at up to 1,200 tags per minute. Features 4-antenna cross-fire geometry, carbon-loaded RF absorber foam lining, and photoelectric opto-isolated GPIO trigger integration with Zebra FX9600 and Impinj Speedway readers.

Key System Capabilities & Features

  • ✓ High-speed singulation throughput up to 1,200 tags per minute across dense carton populations
  • ✓ 4-Antenna cross-fire geometry eliminating tag orientation blind spots
  • ✓ Opto-isolated photocell GPIO triggering to eliminate 24/7 RF radiation and stray reads
  • ✓ Carbon-loaded RF absorber foam lining to suppress internal cavity multipath nulls
  • ✓ Seamless LLRP and OpenRFID middleware integration with ERP/WMS Advance Shipping Notices

Looking for Complete Technical Specifications & Datasheets?

Detailed dimensions, electrical ratings, read range benchmarks, and RF compatibility are available on the official hardware datasheet.

View Datasheet & Specs

RFID Deployment Sizing & Engineering Tools

Validate link budget, tag selection, and hardware compatibility for this equipment setup:

Frequently Asked Questions

How does an RFID tunnel prevent reading stray tags from adjacent warehouse conveyor lines? ▼

The tunnel enclosure is lined with RF absorber foam (ferrite/carbon loaded tiles) and electromagnetic metallic shielding baffles at the entrance and exit curtains, restricting the reader's RF field entirely to the carton passing through the active chamber.

What conveyor belt speeds are supported while maintaining 100% carton read rates? ▼

With four multi-angle circular polarized antennas and readers running high-throughput ROSpecs (such as Zebra FX9600 or Impinj R700), cartons traveling up to 2.5 meters per second (150 meters/minute) achieve 99.98% read accuracy.

Can the tunnel interface directly with conveyor photo-eyes and PLC diverter arms? ▼

Yes. Photo-eye sensors at the entry point trigger the RF scanning field via 24V GPIO inputs, and if an unexpected or non-compliant tag is detected, the reader triggers an immediate GPIO output signal to the PLC pneumatic diverter gate.
