Interactive Simulation: Industrial Smart Emergency Mustering & RFID Headcount Portal
Experience touchless personnel evacuation through an outdoor 4-antenna Zebra FX9600 portal arch. Capture 100+ badges/second, feeding a local offline SKULLSAINTS Onyx Quad-NIC IPC for real-time "Personnel Still Inside" search-and-rescue triage. Looking for the commercial deployment? Explore our Commercial Emergency Mustering System.
⚡ Live Emergency Evacuation & Headcount Simulation Active Roster: 650 • 100+ Tags/Sec • 1.2ms Edge Latency
Press Start to trigger the Code Red evacuation. Industrial workers stream through the 4-antenna portal arch into Assembly Point 1 while the Fire Warden’s tablet tallies headcount in real time.
Industrial Smart Emergency Mustering & RFID Headcount Portal
20 factory workers working calmly on shift. At 3.0s, emergency siren triggers and sounds for 10 seconds: 8 workers evacuate to Assembly Point A (North Gate) and 10 to Assembly Point B (South Gate). At 15.0s muster timeout, the 2 trapped workers inside the facility are declared for emergency search & rescue triage.
| # | TIME | EMP ID | EMPLOYEE NAME | DEPARTMENT | MUSTER LOCATION | STATUS |
|---|---|---|---|---|---|---|
| Click "Start" above to begin simulation and capture live RFID tag reads. | ||||||
Personnel Not Detected / Still Inside Facility (2 Workers)
Generated instantly from local SKULLSAINTS Onyx IPC edge cache: [Active Expected Roster: 20] − [Detected at Muster Points: 18] = [Still Inside: 2]. Hand this sheet directly to Municipal Fire & Rescue.
| Employee ID | Full Name | Department | Last Confirmed Work Station | Assigned Muster | Emergency Contact Phone | Rescue Status |
|---|---|---|---|---|---|---|
| #EMP-1082 | Rajesh Sharma | Chemical Synthesis | Bay 4 Reactor Room (Stuck at Blocked Valve Door) | Point A (North) | +91 98112-44012 (Spouse) | TRAPPED INSIDE |
| #CTR-0491 | Amit Kumar | Boiler Maintenance (Contractor) | Ground Boiler Shed (Stuck at Steam Manifold) | Point B (South) | +91 98711-88201 (Agency Super) | TRAPPED INSIDE |
Smart Emergency Mustering & RFID Headcount System in Action
Watch real-time employee muster point detection, 4-antenna outdoor portal scanning, and instantaneous evacuation headcount updating without physical card-tapping queues.
Why SKULLSAINTS Onyx Quad-NIC Edge IPC is Critical for Disaster Survival
During major factory fires or chemical releases, main electrical feeds trip and WAN fiber connections sever. Cloud-only headcount software fails completely. Our edge architecture runs 100% locally with physical network isolation:
Isolated RFID Subnet
Dedicated private subnet (192.168.10.0/24) directly to Zebra FX9600 readers. Prevents multi-tag burst traffic from flooding plant IT.
Plant OT & PLC
Direct Modbus TCP link to plant automation controllers, emergency horns, and automated muster gate mag-lock releases.
Enterprise HRMS
Secure uplink to corporate network for continuous active shift roster snapshots from SAP SuccessFactors or Darwinbox.
Muster Tablet Wi-Fi
Dedicated Wi-Fi hotspot pushing zero-latency 1-second WebSocket feeds to Fire Warden tablets at outdoor assembly stations.
Standard Emergency Muster Station Hardware BOM
| Component | Model / Type | Key Specification | Role |
|---|---|---|---|
| Industrial Edge PC | SKULLSAINTS Onyx J6412 | Intel Quad J6412, 4x 2.5G Intel i226-V LAN, Fanless Metal | Local OpenRFID engine, SQLite cache, 100% offline survival |
| Fixed UHF Reader | Zebra FX9600 (4-Port / 8-Port) | EPC Gen2v2, 865–867 MHz, -84 dBm sensitivity, IP53 | Multi-tag high-speed capture at muster choke points |
| Outdoor Antennas | Circular Polarized Panels | 9 dBi / 12 dBi, IP67 waterproof enclosure | Creates 3D volumetric detection corridor across gate |
| Long-Range Badges | Printable UHF PVC Cards | Impinj Monza R6-P / NXP UCODE, 6–10m range | Dual-purpose employee photo ID and muster badge |
| Fire Warden Tablet | Industrial Rugged Tablet / iPad | Wi-Fi 6, IP65 drop-resistant, daylight readable | Live headcount stream and Still Inside triage list |
Frequently Asked Questions: Emergency Mustering & Headcount
Why do traditional paper roll calls and biometric turnstiles fail during real plant emergencies?
How does the system operate if factory power and external cloud internet are severed during a disaster?
How does the system identify personnel who are still trapped inside the facility?
Does this system satisfy Indian statutory requirements under the Factories Act, 1948 and ISO 45001?
What hardware components make up a standard emergency muster portal station?
