Asset Tracking
HF Desktop RFID Reader / Writer
USB-Powered 13.56 MHz Reader for Tag Encoding and Verification
Description
The HF Desktop RFID Reader / Writer is a compact, USB-powered desk-top device operating at 13.56 MHz. It is designed for issuing, encoding, and verifying HF RFID and NFC tags, such as library book inlays, employee badges, membership cards, and patient bracelets. Supporting ISO 14443 A/B and ISO 15693 standards out of the box, it requires no external power adapter and plugs directly into a workstation via USB, making it a staple for administrative desks and cataloging stations.
Specifications
- Power
- USB bus-powered, 5 V
- SDK
- Windows / Linux / Android, sample code in C, C++, Java, C#, Python
- Indicators
- Status LED, buzzer beep on read
- Protocols
- ISO 14443 A / B, ISO 15693, NFC Forum Types 1–5
- Interface
- USB 2.0 (HID / CDC virtual serial)
- Frequency
- 13.56 MHz (HF)
- Chip Support
- MIFARE Classic 1K/4K, MIFARE Ultralight, NTAG 213/215/216, ICODE SLIX / SLIX2, FeliCa (optional)
- Material
- ABS desktop puck enclosure
- Working Temp.
- 0 °C to +50 °C
- Read Distance
- 5–10 cm (chip and antenna-dependent)
Customer Reviews
You can write a review now. You will be asked to login on submit.
LoginBe the first to review this product.
Questions
Does this reader require separate power supply?
Can I write data to NFC tags using this reader?
What software does it come with?
